Bell 47 Helicopter Camera Systems
Datatoys, a division of Bad Wolf Technologies LLC, delivers complete airborne video systems built specifically for the Bell 47 helicopter. From flight schools and law enforcement agencies to agricultural operators and tour companies, our solutions provide crystal-clear HD video with the ruggedness and dependability required in aviation.
Designed for straightforward installation, minimal weight impact, and compliance with aviation standards, the Bell 47 package includes HD-SDI bullet cameras, compact airborne DVRs, aircraft-rated mounting hardware, and all essential accessories.
CUSTOMIZED SOLUTIONS AVAILABLE
Need a tailored setup for your Bell 47? We specialize in designing custom video systems to meet unique mission requirements.
BUILT FOR THE BELL 47 PLATFORM
The Bell 47 is one of the most iconic helicopters in aviation history, still actively flying in training schools, agricultural operations, and specialty missions around the world. Our dedicated systems are purpose-designed to endure the Bell 47’s vibration and environmental conditions while offering multiple mounting points for mission flexibility.
Common Bell 47 operations supported by Datatoys video systems include:
- Agricultural and utility flight recording
- Law enforcement surveillance and patrol missions
- Pilot training and flight school review
- Scenic tour recordings for passengers
- Infrastructure and pipeline inspection flights
- Film, TV, and aerial cinematography
Our lightweight, reliable systems are designed to withstand vibration, EMI, and rapid startup environments.
HD NANO BULLET CAMERA – BELL 47 CAMERA
The HD Nano Bullet Camera delivers full high-definition video in a small, rugged package built for aviation use. Powered by a precision Sony Exmor sensor, it delivers low-noise imagery even in variable lighting. Its sealed housing resists vibration and EMI, making it a perfect fit for interior or exterior Bell 47 mounting in survey, patrol, or passenger missions.
SPECIFICATIONS
| Specification | Details |
|---|---|
| Sensor | 2.1 MP, 1/3″ Panasonic Exmor CMOS |
| Video Output | 3G-SDI / EX-SDI / HD-SDI: 1080p60/50, 1080p30/25; CVBS Analog (NTSC/PAL) |
| Dimensions | 19 mm × 56 mm |
| Weight | ~80 g |
| Waterproof Rating | IP67 |
| Lens Options | 20°–115° FOV (2.9, 3.7, 6, 8, 12, 16 mm) |
| OSD Control | Built-in harness for in-field setup |
| Advanced Features | DNR, Day/Night, De-fog, Motion Detection, White Balance |
| Applications | Aviation, UAV, surveillance, Bell 47 operations |
CUBE29 HD-SDI MINI CUBE CAMERA – BELL 47 CAMERA
The CUBE29 Mini Cube Camera is a compact, high-definition solution ideal for Bell 47 cockpits and cabins. Its 29 mm form factor allows discrete mounting while delivering professional-grade video. Built for reliability in vibration-heavy aircraft, the CUBE29 integrates directly with Datatoys AirKnight DVRs.
SPECIFICATIONS
| Specification | Details |
|---|---|
| Video Output | SDI, 3G-SDI |
| Size | 29 mm × 29 mm × 29 mm |
| Image Sensor | 1/2.8” 2.38 MP Sony Exmor CMOS |
| Min. Illumination | Color: 0.2 Lux @ F1.2; B&W: 0.01 Lux @ F1.2 |
| Signal Reliability | EMI-shielded, vibration-resistant |
| Mounting | Ceiling, bulkhead, instrument panel |
HOIST CAMERA – BELL 47 COMPATIBLE
Datatoys offers a helicopter hoist camera option designed for aerial rescue, training, and public safety missions. It is RTCA/DO-160G certified for vibration, shock, EMI, saltwater spray, and submersion, making it well-suited for Bell 47 platforms equipped for specialized hoist operations.
SPECIFICATIONS
| Specification | Details |
|---|---|
| Certification | RTCA / DO-160G aviation qualified |
| Video Output | CVBS, optional HD-SDI/3G-SDI |
| Sensor | 1.3 MP Sony Starvis IMX017 + Eyenix DSP |
| Housing | Waterproof, fog-proof, aircraft-grade aluminum |
| Weight | <1 lb |
| Temperature Range | −40 °C to +55 °C (option to +75 °C) |
| Mounting | Self-contained hoist kit, Bell 47 compatible |
MOUNTING OPTIONS FOR THE BELL 47
| Location | Description |
|---|---|
| Cabin Ceiling | Ideal for passenger or training recording |
| Windshield Support Bar | Forward-facing pilot perspective |
| Rear Frame Bulkhead | Forward or downward passenger view |
| Skid Tube | Exterior scenic or inspection video |
| Instrument Panel Bracket | Compact forward cockpit footage |
DVR OPTIONS FOR THE BELL 47
Datatoys DVRs are engineered to pair with HD-SDI video systems for the Bell 47. All units are aviation-rated, feature removable media, and support multi-channel input.
| DVR Model | Channels | Storage | Features |
|---|---|---|---|
| AirKnight HD | 1–2 | USB, SD | GPS overlay, optional touchscreen, live streaming |
| Red Hawk | Single | SSD + USB | Ruggedized, vibration-isolated, MIL-qualified |
| Corsair | 2–4 | SD cards | Modular, multi-encoder, streaming ready |
POPULAR BELL 47 CAMERA SETUPS
| Mission | Recommended System | Notes |
|---|---|---|
| Flight Tours | 2 cameras (passenger + forward) + DVR | Optional audio sync |
| Law Enforcement | Cabin cam + external cam + DVR | GPS tagging available |
| Pilot Training | Forward cockpit + cabin cam + DVR | Perfect for maneuver review |
| Agricultural/Utility | Forward cam + GPS-enabled DVR | Stamped data for inspections |
| Media/Film | External + cabin cam + AirKnight DVR | Fast export for editing |
VIDEO OUTPUT FORMATS
All Bell 47 kits include HD-SDI output for uncompressed 1080p60 video. Optional CVBS output is available for older displays or redundancy.
| Output | Application |
|---|---|
| HD-SDI (1080p60) | Real-time viewing, mission recording |
| CVBS (480i) | Legacy monitor compatibility |
| Dual Output | Both HD and SD from a single camera |
WHY OPERATORS CHOOSE DATATOYS FOR THE BELL 47
- Lightweight, compact hardware tailored to the Bell 47 airframe
- Cabling designed for clean routing in older and modern builds
- Quick installation with minimal aircraft downtime
- Instant power-on with aircraft startup
- GPS tagging and audio sync capability
- Removable storage for simple data transfer
- U.S. engineering support and documentation for compliant installs
WHO USES DATATOYS SYSTEMS IN THE BELL 47
- Flight schools training new pilots
- Agricultural operations and crop monitoring teams
- Law enforcement and sheriff air units
- Cinematographers and aerial film crews
- Infrastructure inspection and survey teams
- Private operators seeking flight documentation
REQUEST YOUR BELL 47 VIDEO SYSTEM
Every Bell 47 package is built to order. Your system can include:
- HD-SDI bullet and cube cameras
- Datatoys DVR of choice
- Installation hardware and mounts
- GPS tagging and audio integration
- Aviation-rated cabling and connectors
- User documentation for quick start
CONTACT US
Ready to outfit your Bell 47 with a mission-ready video system? Reach out to our team today for a quote or technical consultation.
