BELL 206 JET RANGER CAMERA SYSTEMS – RUGGED HD VIDEO KITS FOR TOUR, PATROL, SURVEILLANCE, AND TRAINING
Bad Wolf Technologies LLC, home of Datatoys video systems, delivers complete airborne video solutions built specifically for the Bell 206 Jet Ranger. Trusted worldwide for its reliability, the Bell 206 deserves mission-ready video systems engineered for aviation from the ground up.
Whether your mission involves power line patrol, tactical surveillance, flight training, or scenic air tours, Datatoys systems provide durable, high-definition video capture proven across industries.
Designed for quick installation, minimal footprint, and compliance with aviation standards, the Bell 206 solution includes HD-SDI bullet cameras, compact airborne DVRs, aircraft-rated mounts, and all required accessories.
BUILT FOR THE BELL 206 PLATFORM
Unlike ground-adapted systems, Datatoys equipment is aviation-first. Every recorder, camera, and cable is designed from the start for rotorcraft operations, ensuring the system can withstand vibration, EMI, rapid power cycling, and environmental extremes.
This means operators get better durability, seamless integration, and simplified installation across all mission types.
Common Bell 206 missions that benefit from onboard video systems include:
- Utility operators conducting pipeline and power line patrols
- Tour companies recording scenic passenger flights
- Law enforcement aviation units performing surveillance and SAR
- Flight schools capturing cockpit training sessions
- News and media teams gathering onboard footage
- Emergency response and firefighting support flights
RECOMMENDED EQUIPMENT FOR THE BELL 206
To keep configurations simple yet powerful, we recommend three core components that cover most missions. These products are flight-tested, durable, and integrate cleanly with Jet Ranger systems.
HD NANO BULLET CAMERA – RUGGED EXTERIOR FOOTAGE IN FULL HD
The HD Nano Bullet Camera is purpose-built for external mounting on the Bell 206. Its compact form factor, weatherproof housing, and Sony CMOS sensor make it ideal for capturing sharp 1080p video in real-world aviation conditions.
| SPECIFICATION | DETAILS |
|---|---|
| Sensor | 2.16 MP Sony CMOS |
| Video Output | 3G-SDI / HD-SDI (1080p60/50, 1080i, 720p) + CVBS |
| Dimensions | 19 × 56 mm |
| Weight | ~75 g |
| Waterproof Rating | IP67, EMI-resistant |
| Lens Options | 20°–130° field of view |
| Applications | External scenic recording, patrol, hoist monitoring, inspections |
CUBE29 HD-SDI MINI CUBE CAMERA – COMPACT INTERIOR OR CHIN-BUBBLE CAMERA
The CUBE29 camera fits where space is limited but high-quality video is required. It provides excellent clarity in low light and integrates easily into the cockpit or cabin without obstructing crew or passenger space.
| SPECIFICATION | DETAILS |
|---|---|
| Video Output | 3G-SDI / HD-SDI |
| Sensor | 1/2.8” Sony Exmor CMOS (2.38 MP) |
| Dimensions | 29 × 29 × 29 mm |
| Minimum Illumination | 0.01 lux B&W, 0.2 lux color |
| Mounting Options | Ceiling, bulkhead, windshield support bar |
| Applications | Cabin footage, pilot training, scenic tours |
AIRKNIGHT HD DVR – THE CENTRAL RECORDING HUB
The AirKnight HD DVR is the backbone of Datatoys systems. It records synchronized video, GPS, and audio data in real time, while offering streaming and export options for flexible mission use.
| SPECIFICATION | DETAILS |
|---|---|
| Channels | 1–2 |
| Inputs | 3G-SDI, HDMI, CVBS, RS170 |
| Storage | USB / SD / SSD (removable) |
| Features | GPS overlay, multi-channel recording, LAN streaming, audio integration |
| Applications | Mission recording, flight training, law enforcement, tour operations |
POPULAR BELL 206 CAMERA SYSTEM CONFIGURATIONS
Operators rely on Datatoys systems to support a wide range of mission types. Below are common configurations we recommend for the Jet Ranger platform.
| MISSION TYPE | RECOMMENDED SETUP | NOTES |
|---|---|---|
| Flight Tours | 2 cameras (external + cabin) + DVR | Capture panoramic views and passenger reactions. Videos can be sold instantly via USB or digital delivery. |
| Utility & Pipeline Patrol | External HD Nano camera + GPS-enabled DVR | Provides GPS overlays and geo-tagged footage for infrastructure inspections. |
| Law Enforcement / Tactical | External + cockpit cameras + DVR (FLIR integration optional) | Evidence-grade capture with GPS/audio sync. Compatible with gimbals. |
| Training Flights | Cockpit + chin bubble cameras + DVR | Supports instructor/student review with instant video playback. |
| Media & News | Cabin + external skid camera + AirKnight DVR | Professional-grade recording with removable storage for fast editing. |
MOUNTING OPTIONS FOR THE BELL 206
Datatoys offers flexible mounting solutions that integrate with existing Jet Ranger airframes. Options are designed for minimal footprint and optimal coverage.
| MOUNT LOCATION | DESCRIPTION |
|---|---|
| Cabin / Ceiling | Passenger-facing or wide cabin coverage |
| Windshield Support Bar | Cockpit-focused recording or training footage |
| Rear Cabin Wall | Forward-facing passenger view |
| Skid Tube / External Frame | Scenic or patrol footage from outside the aircraft |
| Instrument Panel Bracket | Compact forward-facing cockpit option |
HD-SDI AND ANALOG VIDEO OUTPUT SUPPORT
Datatoys systems are built for compatibility with both modern and legacy infrastructures, giving operators flexibility in how they use and upgrade their equipment.
| OUTPUT FORMAT | APPLICATION |
|---|---|
| 3G-SDI / HD-SDI (1080p60) | Uncompressed real-time viewing and HD recording |
| CVBS NTSC / PAL, RS170 | Supports legacy monitors and recorders |
| Dual Output (HD + SD) | Redundant feeds or compatibility with mixed systems |
KEY MISSION APPLICATIONS
Utility and Pipeline Patrol
Mounted HD Nano bullet cameras deliver long-distance corridor footage with GPS overlays. Operators use recordings for inspection reports, vegetation monitoring, and mapping.
Flight Tours
Tour operators maximize revenue by selling branded, ready-to-go videos. Datatoys systems capture both exterior views and passenger reactions with picture-in-picture or multi-camera switching.
Law Enforcement & Tactical
Compatible with FLIR and EO/IR gimbals, the AirKnight DVR records synchronized GPS, video, and audio for evidence-grade surveillance and SAR missions.
Training & Flight Schools
Flight schools use cockpit and chin bubble cameras for post-flight debriefs. Students and instructors gain instant video feedback, improving safety and efficiency.
WHY CHOOSE DATATOYS FOR YOUR BELL 206
- Aviation-rated hardware designed specifically for rotorcraft
- Lightweight, compact systems that integrate seamlessly with the Jet Ranger
- Plug-and-play installation with minimal downtime
- Proven durability against vibration, EMI, and temperature shifts
- US-based engineering and integration support
READY TO BUILD YOUR BELL 206 VIDEO SYSTEM?
Bad Wolf Technologies / Datatoys specializes in turnkey helicopter video systems. Each package is tailored to your mission profile and includes cameras, DVRs, mounts, and aviation-grade cabling—everything you need to start recording immediately.
